Eaton EGS3020FFB Molded Case Fixed Circuit Breaker

Product Description

The EATON EGS3020FFB is a molded case circuit breaker with a fixed mounting configuration. Molded case circuit breakers provide overcurrent and short-circuit protection in electrical distribution systems. This unit is installed in load centers, panelboards, and switchgear applications where reliable branch or feeder circuit protection is required. Licensed electricians and electrical contractors are the primary installers. The fixed configuration means the breaker is non-interchangeable within the enclosure, providing a secure and permanent installation suited for commercial and residential electrical systems.

The EGS3020FFB is suited for use in branch circuit and feeder applications within electrical distribution panels. It fits both commercial and residential electrical systems where fixed-mount molded case breakers are specified. The fixed frame style makes it appropriate for installations requiring a dedicated, non-removable protective device in panelboard or switchgear assemblies.

Key Features

• Molded case construction provides durable housing and internal arc isolation
• Fixed mounting configuration for permanent panelboard or switchgear installation
• Designed for overcurrent and short-circuit protection in branch or feeder circuits
• Compact form factor suitable for space-constrained electrical enclosures

Compatibility

Designed as an OEM-style replacement or direct-fit molded case circuit breaker for compatible EATON panelboards and switchgear assemblies accepting fixed-mount breakers of this frame size.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the panelboard or switchgear before handling or installing the breaker. Verify that the bus bar rating and enclosure specifications are compatible with this breaker before installation. Do not modify the breaker housing or internal components.

Technical Specifications

• Mounting Type: Fixed
• Breaker Type: Molded Case
• Length: 6.5 inches
• Width: 4 inches
• Height: 4.25 inches
• Weight: 2.9 pounds
• UPC: 78668538211

Standard Information

• Brand: EATON
• Manufacturer Part Number: EGS3020FFB
