Eaton EGB3030FFG Molded Case Circuit Breaker, 30A, 600Y/347 Vac, Fixed Thermal, Fixed Magnetic Trip

Product Description

The Eaton EGB3030FFG is a molded case circuit breaker designed to provide reliable circuit protection. It features a three-pole configuration with a current rating of thirty amperes. This product operates at voltages of six hundred Y/three hundred forty-seven volts AC and has interruption capabilities of 25 kAIC at two hundred forty volts and 18 kAIC at four hundred eighty volts. The Eaton brand is recognized for its robust and high-quality electrical solutions.

• High-speed blow-open action for superior performance
• UL Listed, CSA Certified, and IEC Rated
• Suitable for electrical assemblies and panels

Product Highlights

This circuit breaker allows for easy installation and custom configuration, making it ideal for various applications.

Product Information

Standard Information

• Manufacturer: Eaton
• Manufacturer Part Number: EGB3030FFG

Technical Specifications

• Amperage Rating: 30 A
• Voltage Rating: 600Y/347 Vac
• Number of Poles: 3
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 18 kAIC at 480 Vac | 25 kAIC at 240 Vac
• Frame: EG
• Trip Type: Fixed thermal, fixed magnetic
• Country of Origin: Dominican Republic
