Eaton EDSC3129 ED Snap Switch Control Station 20A 1G Enclosure 2504424016

Product Description

The Eaton EDSC3129 is a snap switch control station designed for industrial settings. This product features a single-gang enclosure with one-pole switching capability for reliable power distribution and control. The unit is made from Feraloy iron alloy and is suited for use in hazardous environments.

• Voltage rating ranges from 120 to 277 VAC
• Amperage rated for twenty amps
• UL and CSA certified for safety

Product Highlights

Designed to meet the needs of industrial facilities, the Eaton EDSC3129 provides robust performance for reliable operation. This control station ensures safe distribution of power while facilitating easy installation with its single-gang design.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Crouse Hinds

Technical Specifications

• Type: Snap switch control station
• Weight: 8.5 lbs
• Dimensions: 5.875 inches length x 3.5 inches width x 3.0625 inches height
• Material: Feraloy
• Voltage Rating: 120 to 277 VAC
• Amperage Rating: 20 A
• Number Of Poles: 1
• Special Features: Factory sealed
