Eaton ED3200 Electrical ED3200 Series C F Frame Molded Case Circuit Breaker 200 A 240 Vac 125 Vdc 65 kAIC at 240 Vac

Product Description

Eaton ED3200 is a Series C F Frame molded case circuit breaker designed for effective branch circuit protection. This model is a durable option for panelboards, switchboards, motor control centers, and busway applications. With a fixed thermal and fixed magnetic trip type, this three-pole breaker supports a maximum current rating of two hundred amps at two hundred forty volts alternating current and one hundred twenty-five volts direct current.

• Fixed thermal and magnetic trip type
• Conducts up to two hundred amps
• Interrupt rating of sixty-five kAIC at two hundred forty volts

Product Highlights

This circuit breaker is ideal for electrical assemblies, panels, and OEM applications. Its reliable design meets North American standards and is suitable for voltages up to six hundred VAC or two hundred fifty VDC.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer Part Number: ED3200

Technical Specifications

• Current Rating: 200 A
• Voltage Rating: 240 Vac, 125 Vdc
• Number of Poles: 3
• Frame Type: F
• Frequency Rating: 50-60 Hz
• Interrupt Rating: 65 kAIC
• Applications: Electrical assemblies, panels, and OEMs
• Country of Origin: Dominican Republic
