Eaton ED3100 Series C F Frame Molded Case Circuit Breaker 100 A 3 Pole

Product Description

Eaton ED3100 is a Series C molded case circuit breaker designed for electrical safety and protection. This three-pole breaker provides reliable circuit protection at a current rating of one hundred amperes and is rated for two hundred forty volts alternating current and one hundred twenty-five volts direct current. The ED3100 features a fixed thermal and fixed magnetic trip type, ensuring protection from overloads and short circuits.

• Current Rating: 100 A
• Interrupt Rating: 65 kAIC at 240 Vac
• Frequency: 50/60 Hz

Product Highlights

This circuit breaker is ideal for use in panelboards, switchboards, and motor control centers, offering high performance in a compact design.

Product Information

Standard Information

• Manufacturer: Eaton
• Catalog Number: ED3100

Technical Specifications

• Type: Molded case circuit breaker
• Frame: F
• Number of Poles: 3
• Voltage Rating: 240 Vac, 125 Vdc
• Weight: 4.5 lb
• Dimensions: 3.38 in L x 4.13 in W x 6 in H
• Application: Electrical assemblies, panels, and EOEM
