EATON ED3050 ED Molded Case Circuit Breaker, 240 VAC/125 VDC, 50 Amp, 65 kAIC, 3 Poles

Product Description

The EATON ED3050 is a molded case circuit breaker designed for reliable circuit protection in various applications. It provides a voltage rating of 240 VAC and 125 VDC with a 50 amp current capacity. The breaker has a 65 kAIC interrupt rating at 240 VAC, ensuring effective protection against overloads and short circuits. This three-pole circuit breaker features a fixed thermal and fixed magnetic trip mechanism.

• Voltage rating: 240 VAC/125 VDC
• Current rating: 50 Amps
• Interrupt rating: 65 kAIC at 240 VAC

Product Highlights

The EATON series offers dependable branch circuit protection for panelboards, switchboards, and motor control centers. The design supports reverse feed applications and is UL listed for safety compliance.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part No: ED3050

Technical Specifications

• Type: Type ED
• Frame: F
• Series: C Series
• Trip Type: Fixed Thermal/Fixed Magnetic
• Dimensions: 3.38 x 4.13 x 6 inches
• Number of Poles: 3
• Frequency Rating: 50/60 Hz
• Country of Origin: Dominican Republic
