Eaton ED2050 ED Molded Case Circuit Breaker 240 VAC 50 Amp 65 kAIC

Product Description

Eaton ED2050 is a molded case circuit breaker designed to provide reliable circuit protection. This model operates at 240 VAC and 125 VDC with a current rating of 50 amps and an interrupt rating of 65 kAIC. It features two poles and is suitable for various applications including panelboards and motor control centers.

• Reliable circuit protection at 240 VAC and 125 VDC
• Fixed thermal and fixed magnetic trip type
• 65 kAIC interrupt rating for enhanced safety

Product Highlights

The Eaton ED2050 circuit breaker is suitable for panel mounting and provides superior performance due to its patented contact design. The breaker is recognized for its user acceptance and meets North American standards for electrical safety.

Product Information

Standard Information

• Brand: Eaton
• Catalog Number: ED2050
• Frame: F

Technical Specifications

• Voltage Rating: 240 VAC, 125 VDC
• Amperage Rating: 50 A
• Number of Poles: 2
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 65 kAIC
• Temperature Rating: 40 deg C
• Size: 3.38 in L x 2.75 in W x 6 in H
