Eaton E51CNP5 Photoelectric Sensor 15 Feet, 1A Max Ac, 120 VAC Input

Product Description

The Eaton E51CNP5 is a limit switch style modular photoelectric sensor with a 15 ft sensor distance. This sensor is suitable for various sensing applications, with options including thru-beam, reflex, polarized reflex, diffuse reflective, and fiber optic modes. It features a plastic enclosure and a 1.0A max AC, 120 Vac input.

• Features a selector switch for light or dark operation
• Components are interchangeable with E51 proximity sensors
• Rugged construction ideal for industrial environments

Product Highlights

The E51 series modular sensors are easy to maintain and offer flexibility for a wide range of sensing needs.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: E51CNP5
• Country of Origin: US

Technical Specifications

• SKU: E51CNP5
• Type: Photoelectric Sensor Head
• Contact Rating: 1.0A Solid State Output
• Enclosure material: Plastic
• Operating mode: Polarized retroreflective
• Connection: Screw terminal
• Contact configuration: L1 switched, NO/NC
• Series: E51
• Sensor type: Through beam detector
• Switch type: Photoelectric
• Input voltage: 120 Vac
• Maximum AC current: 1 A
• Operating temperature - max: 158 °F
• Operating temperature - min: -13 °F
• Environmental rating: NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP67
• Product Length/Depth: 1.84 in
• Product Height: 1.86 in
• Product Width: 1.54 in
• Warranty: 3 year
• Compliances: CE Marked
• Certifications: UL Listed CSA Certified
• Catalog Notes: Assembled sensor with head; sensor body and receptacle. Logic modules must be ordered separately.
• Product Type: Limit switch photoelectric sensor
• NEMA Protection: NEMA 3S
• IP Protection: IP69K
• Temperature Range: -13 °F - 158 °F
• Contact Configuration: 1 NC Or 1 NO
• Enclosure Composition: Plastic
• Component: Modular Sensors
• Height (cm): 4.72
• Length (cm): 4.67
• Width (cm): 3.91
• Country Of Origin: US
• Weight (kg): 0.081
