Eaton E50TD1 NEMA Heavy Duty Plug-In Limit Switch

Product Description

The Eaton E50TD1 is a NEMA heavy-duty plug-in limit switch. This limit switch offers design versatility and high reliability for industrial applications. It features chemical-resistant FKM gaskets, seals, and boots, along with a die-cast zinc enclosure. Mounting dimensions accommodate U.S. and DIN standards for easy installation.

• Modular, plug-in components provide application flexibility and reduced downtime.
• Manufactured to withstand physical and environmental stress, including cutting fluids and chemicals.
• Heads and switch bodies can be replaced without rewiring.

Product Highlights

The Eaton E50TD1 limit switch is suitable for machine tool, automotive, wastewater treatment, and other heavy-duty industrial applications.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: E50TD1
• Country of Origin: MEX

Technical Specifications

• Product Name: Eaton E50 NEMA heavy duty plug-in limit switch
• Catalog Number: E50TD1
• UPC: 782113290713
• Product Length/Depth: 4.22 in
• Product Height: 2.46 in
• Product Width: 1.54 in
• Compliances: CE Marked, RoHS Compliant
• Certifications: UL Listed, CSA Certified
• Product Type: Heavy duty plug-in limit switch
• Type: Limit Switch
• Contact Rating: 10 A at 12 VAC, 1 A at 125 VDC
• Cable type: SOOW-A
• Enclosure material: Die cast zinc
• Connection Type: Screw Terminal
• Contact Configuration: 1 NO-1 NC
• Series: E50
• Switch type: Convertible, Two-step CW, CCW, Side rotary
• Operating temperature - max: 201 °F
• Operating temperature - min: 14 °F
• Environmental rating: NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67
• Maximum AC current: 10 A
• Maximum DC current: 1 A
• UNSPSC: 39122213
• Material: Die Cast Zinc
• Application: Industrial Facilities and Factories and Other, Automation and Logic Control Equipment Applications
• Actuator: Side Rotary
• Operating Temperature: 14 to 201
• Size: 4.22 in L x 1.54 in W x 2.46 in H
• Enclosure Type: NEMA 1/3/3S/4/4X/6/6P/13/IP67
• Amperage: 10
• Voltage: 240VAC
• Mounting Type: Panel
• Approval: CE, UL, CSA
• Terminal Connection: Screw
• Nema Rating: 1, 3, 3S, 4, 4X, 6, 6P, 13
• Length (in): 4.22
• Width (in): 1.54
• Height (in): 2.46
• Standards: NEMA, RoHS
• Temperature Rating: 14 to 201 °F
• Duty Rating: Heavy Duty
• Actuator Type: Side Rotary
• Mpn: E50TD1
• Gtin: 782113290713
• Package Qty: 1.0000
• Manufacture: EATON CORPORATION
• Mfr Catalog Number: E50TD1
• Product Group: EA45
• Product UPC: 78211329071
• Product Category: Special Purpose Roller Le
• Commodity Code: 4613
• Unique Product Key: 359769
• PC W ALT DESC: 2NO-2NC CONTACT CONFIGURATION; 1/2 INCH NPT/20 MM
• PC W COMMODITY CODE: 4613
• PC W ID: 359769
• PC W STK STATUS NUM: 2
• Category: Eaton E50 Heavy-Duty Plug-In Switches, Assembled - Special Purpose
• Vendor: Eaton (Electrical)
• Vendor ID: E50TD1
• Alternate Code: EA
• Component: Limit Switch
• (Instrument-Sensor) NEMA Protection: NEMA 3S
• (Instrument-Sensor) Connection Type: Screw Terminal
• (Instrument-Sensor) IP Protection: IP67
• (Instrument-Sensor) Contact Configuration: 1 NO + 1 NC
• Manufacturer: Eaton
• Sub Component: Heavy-Duty Plug-In Switch
• (Instrument-Sensor) Enclosure Composition: Die Cast Zinc
• (Instrument-Sensor) Temperature Range: 14 °F - 201 °F
