Eaton E50KL340 nema heavy duty plug-in limit switch operator

Product Description

The Eaton E50KL340 is a NEMA heavy-duty plug-in limit switch operator. Designed for use with side rotary switches, it features a precision adjustable roller. The lever is constructed from aluminum, while the roller is made from nylatron. Suitable for industrial facilities and factories applications.

• Precision adjustment
• Heavy duty plug-in limit switch accessory
• NEMA 1/3/4/6/13/3S/4X/6P/IP67/IP69K enclosure rating

Product Highlights

The Eaton E50KL340 limit switch operator offers precision and durability for demanding industrial environments.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: E50KL340
• Country of Origin: United States

Technical Specifications

• Product Name: Eaton E50 NEMA heavy duty plug-in limit switch operator
• Catalog Number: E50KL340
• UPC: 782113308678
• Product Length/Depth: 0.75 in
• Product Height: 1.52 in
• Product Width: 0.78 in
• Product Weight: 0.09 lb
• Warranty: 1 year
• Compliances: RoHS Compliant CE Marked
• Certifications: UL Listed CSA Certified CE
• Catalog Notes: Lever length is from the operating shaft axis to the roller axis. Maximum roller length dimension between operating shaft axis to the roller axis for comparison. Precision adjustable to lesser dimensions.
• Product Type: Heavy duty plug-in limit switch accessory
• Special features: Precision adjustment
• Type: Precision Adjustment Roller
• Cable type: SOOW-A
• Enclosure material: Lever: aluminum Roller: nylatron
• Series: E50
• Switch type: Lever for side rotary switches
• Operating temperature - max: 201 °F
• Operating temperature - min: -40 °F
• Environmental rating: NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67, IP69K
• Material: Roller: Nylatron Lever: Aluminum
• Approval: CE, UL, CSA
• Nema Rating: 1, 3, 3S, 4, 4X, 6, 6P, 13
• Length (in): 0.75
• Width (in): 0.78
• Height (in): 1.52
• For Use With: Side Rotary Switches
• Standards: NEMA, RoHS
• Temperature Rating: -40 to 201 °F
• Duty Rating: Heavy Duty
• Actuator Type: Adjustable Roller
• Mpn: E50KL340
• Gtin: 782113308678
• Condition: New
• Brand: Cutler Hammer
• Specific: Overall Length: 2-3/8"
• Specific: Roller Diameter: 3/4"
• Model: E50KL340
• Country of Origin: United States
• IP/NEMA Rating: NEMA 1, IP69K, IP67, NEMA 4X, NEMA 4
• Arm Length: 0.69 in
• Roller Diameter: 3/4 in
• Roller Width: 0.32
• Roller Material: Nylatron
• Arm Material: Aluminum
• UNSPSC: 39122213
• Application: Industrial Facilities and Factories Applications
