Eaton E50GG1 Heavy Duty Limit Switch Side Rotary

Product Description

The EATON E50GG1 is a heavy-duty limit switch designed for exceptional chemical resistance. Its modular, plug-in components offer application flexibility, reduced inventory, and less downtime. Constructed to endure physical and environmental stress, it is ideal for harsh industrial settings. The switch features screw terminal connections and a side rotary actuator.

• Features a 1NO-1NC contact configuration.
• Enclosure is NEMA 1/3/3S/4/4X/6/6P/13/IP67 rated.
• Operating temperature range of 14 to 201 deg F.

Product Highlights

This heavy-duty limit switch is built to withstand harsh industrial environments and offers reliable performance with its robust construction and chemical resistance.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: E50GG1

Technical Specifications

• Actuator: Side Rotary
• Application: Cutting and Forming, Punch Presses, Waste Water Treatment, Machine Tool, Automotive, Retrieval Systems, Industrial Truck and Car Wash Lines Applications
• Connection Type: Screw Terminal
• Contact Configuration: 1NO-1NC
• Contact Rating: 5 A at 250 VAC
• Enclosure: NEMA 1/3/3S/4/4X/6/6P/13/IP67
• Manufacturer Part Number: E50GG1
• Material: Die Cast Zinc
• Mounting Type: Threaded
• Operating Cycles: 13000000 cycles
• Operating Temperature: 14 to 201 deg F
• Series: E50
• Size: 4.22 in L x 1.54 in W x 2.46 in H
• Standards/Approvals: CE Certified|CSA Certified|IEC.947.5.1|RoHS Compliant|TUV E9271605E02|UL Listed
• Type: Heavy Duty Gravity Return Plug-In
• Product Name: Eaton E50 NEMA heavy duty plug-in limit switch
• UPC: 782113304090
• Product Length/Depth: 4.22 in
• Product Height: 2.46 in
• Product Width: 1.54 in
• Product Weight: 0.5 lb
• Warranty: 1 year
• Compliances: RoHS Compliant
• Certifications: CSA Certified UL Listed
• Product Type: Heavy duty plug-in limit switch
• Cable type: SOOW-A
• Connection: Screw terminal
• Switch type: Gravity return Side rotary
• Operating temperature - max: 201 °F
• Operating temperature - min: 14 °F
• Environmental rating: NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67
• Maximum AC current: 5 A
• Category: Switches, Limit Switches
• Voltage Rating - AC: 250 V
• Electrical Life: 100,000 Cycles
• Current Rating (Amps): 5A (AC)
• Circuit: SPDT
• Mechanical Life: 13,000,000 Cycles
• Switch Function: On-On
• Part Status: Active
• Ingress Protection: IP67 - Dust Tight, Waterproof
• Termination Style: Screw Terminal
• Brand: Eaton/Cutler-Hammer
• Amperage: 10
• Voltage: 240VAC
• Approval: CE, UL, CSA
• Terminal Connection: Screw
• Nema Rating: 1, 3, 3S, 4, 4X, 6, 6P, 13
• Length (in): 4.22
• Width (in): 1.54
• Height (in): 2.46
• Standards: NEMA, RoHS
• Temperature Rating: 14 to 201 °F
• Duty Rating: Heavy Duty
• Enclosure Material: Die Cast Zinc
• Mpn: E50GG1
• Gtin: 782113304090
• Condition: New
