Eaton E50BM1 Heavy Duty Plug in Limit Switch

Product Description

The EATON E50BM1 is a heavy duty plug-in limit switch designed for industrial control and automation applications. Limit switches of this type sense the presence, position, or movement of machinery components and convert that mechanical input into an electrical signal that controls a circuit. The E50BM1 uses a plug-in body design, which separates the switch head from the operating mechanism and allows the contact block to be replaced without disturbing the conduit wiring. Licensed electricians and industrial maintenance technicians are the typical installers. The unit measures 4.25 inches long by 3 inches wide by 1.75 inches high and weighs 1.22 pounds.

This limit switch is suited for use in industrial machinery, conveyor systems, material handling equipment, and process control panels where reliable position detection is required. The plug-in configuration is commonly chosen in applications where contact block replacement speed matters and minimizing downtime is a priority. It is appropriate for both light manufacturing and heavier-duty industrial environments where mechanical durability and consistent electrical performance are required from the control circuit components.

Key Features

• Plug-in body design allows contact block replacement without disturbing conduit wiring
• Heavy duty construction rated for demanding industrial environments
• Compact form factor: 4.25 inches x 3 inches x 1.75 inches
• Lightweight at 1.22 pounds for ease of mounting and handling
• Suitable for position sensing and machine guarding control circuits

Compatibility

Designed as an OEM-style replacement or direct-fit plug-in limit switch for industrial control and automation systems requiring a heavy duty plug-in body configuration.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements and local electrical codes. Disconnect and lock out all power to the control circuit before removing or installing the switch. Verify that the actuator alignment and mounting orientation match the mechanical travel path of the machinery before securing the unit. Do not exceed the electrical ratings of the contact block during circuit design or replacement.

Technical Specifications

• Length: 4.25 inches
• Width: 3 inches
• Height: 1.75 inches
• Weight: 1.22 pounds
• UPC: 78211336183

Standard Information

• Brand: EATON
• Manufacturer Part Number: E50BM1
