Eaton E50AW1Y1 Heavy Duty Plug-In Limit Switch, Screw Terminals, 10A at 240Vac, 1A at 250Vdc, 1NO-1NC

Product Description

The Eaton E50AW1Y1 is a heavy-duty plug-in limit switch. This switch features screw terminals and is rated for ten amps at two hundred forty volts alternating current and one amp at two hundred fifty volts direct current. The device design meets industry standards for reliability and low maintenance. It is suitable for demanding environments including automotive and wastewater applications.

• Contact Configuration: 1 NO-1 NC
• Operating Temperature Range: 14 to 250 degrees Fahrenheit
• Enclosure Type: NEMA rated 1, 3, 3S, 4, 4X, 6, 6P, 13, IP67

Product Highlights

This Eaton limit switch features quick installation and a wide range of applications.

Product Information

Standard Information

• Manufacturer: Eaton
• UPC: 782114426654

Technical Specifications

• Catalog Number: E50AW1Y1
• Connection Type: Screw terminal
• Material: Die cast zinc
• Series: E50
• Size: 1.54 inches L x 1.78 inches W x 4.93 inches H
• Contact Rating: 10 A at 240 Vac, 1 A at 250 Vdc
• Country of Origin: Mexico
• Application: Water and wastewater systems; Machine tools
