Eaton E50ANS1 E50 NEMA heavy duty plug-in limit switch

Product Description

The Eaton E50ANS1 is a NEMA heavy-duty plug-in limit switch. This limit switch features a side pushbutton, spring return, and neon indicator. It is suitable for a wide range of industrial applications. It is constructed from die-cast zinc and is UL and CSA certified.

• Heavy-Duty Plug-In Type
• Die Cast Zinc Construction
• NEMA 1, 3, 3S, 4, 4X, 6, 6P, 13, IP67 rated

Product Highlights

The EATON E50ANS1 limit switch is a reliable choice for demanding industrial settings, offering design flexibility and resistance to harsh environments.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: E50ANS1

Technical Specifications

• Product Name: Eaton E50 NEMA heavy duty plug-in limit switch
• Catalog Number: E50ANS1
• UPC: 782113343983
• Product Length/Depth: 4.22 in
• Product Height: 2.25 in
• Product Width: 1.54 in
• Product Weight: 1.1 lb
• Compliances: CE Marked
• Certifications: CSA Certified UL Listed
• Product Type: Heavy duty plug-in limit switch
• Contact Rating: 10A at 240Vac, 1A at 125Vdc
• Enclosure material: Die cast zinc
• Connection: Screw terminal
• Contact configuration: 1 NO-1 NC
• Switch type: Side pushbutton
• Operating temperature - max: 201 F
• Operating temperature - min: 14 F
• Environmental rating: NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67
• Maximum AC current: 10 A
• Maximum DC current: 1 A
• LED indicator: Neon (120 Vac)
• Manufacturer Part Number: E50ANS1
• Manufacturer: Eaton
• Product Series: E50
• Family Series: Eaton Limit Switches, E50 Series
• Description: Eaton E50 NEMA heavy duty plug-in limit switch,Within 0.003,Screw Terminals,10A at 240Vac,1A at 125Vdc,1NO-1NC,Die Cast Zinc,NEMA 1,3,3S,4,4X,6,6P,13,IP67,Neon 120 Vac ,10A,1A,14 to 201 F -10 to 94 C,Side Pushbutton
• Actuator Type: Side Plunger
• Contacts: 1NO/1NC
• Conduit Fitting: 1/2 NPT
• Indicator: Yes
• NEMA Rating: NEMA 1, NEMA 13, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 3S
• Approvals: CSA, TUV, UL
• Material: Zinc
• Net Weight: 1.1063 lbs
• Gross Weight: 1.1063 lbs
• Component: Limit Switch
• (Instrument-Sensor) NEMA Protection: NEMA 3S
• (Instrument-Sensor) Connection Type: Screw Terminal
• (Instrument-Sensor) IP Protection: IP67
• (Instrument-Sensor) Contact Configuration: 1 NO + 1 NC
• (Instrument-Sensor) Actuator: Side Rotary
• Sub Component: Heavy-Duty Plug-In Switch
• (Instrument-Sensor) Enclosure Composition: Die Cast Zinc
• (Instrument-Sensor) Temperature Range: 10 F - 200 F
• (Instrument-Sensor) Contact Rating: 10 Amp At 12 VAC
