Eaton E34SP42 Standard Type Push Button 30.5mm

Product Description

The EATON E34SP42 is a standard type push button operator with a 30.5mm mounting diameter, designed for industrial and commercial control panel applications. This operator serves as the physical interface between a machine operator and the control system, actuating contactors, relays, or other downstream devices. Licensed electricians and control panel technicians install this type of component during panel builds, machine retrofits, and equipment maintenance. The 30.5mm format is a widely recognized standard in heavy-duty operator station assemblies.

The E34SP42 is suited for use in operator stations, control enclosures, and machine control panels found in industrial and commercial environments. It is appropriate for applications requiring a reliable, standard-format push button operator where panel space, mounting standardization, and consistent actuation force matter. Installation typically occurs as part of a new panel build or as a drop-in replacement for a worn or failed operator in an existing 30.5mm cutout.

Key Features

• Standard type push button operator in the 30.5mm mounting format
• Designed for industrial and commercial control panel use
• Compatible with standard 30.5mm panel cutout installations
• Built for reliable operator-to-control-system interface in machine environments

Compatibility

Designed as an OEM-style replacement or new-installation push button operator for control panels and operator stations with a standard 30.5mm mounting cutout.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements. De-energize the control panel and verify zero voltage at the terminals before removing or installing any operator component. Standard panel punch or knockout tools are used to prepare the 30.5mm mounting hole if installing in a new enclosure. Ensure the operator is fully seated and the mounting nut is secured before restoring power.

Technical Specifications

• Mounting Diameter: 30.5mm
• Type: Standard Push Button Operator
• Weight: 1 pound
• UPC: 78211370473

Standard Information

• Brand: EATON
• Manufacturer Part Number: E34SP42
