Eaton E34L1 Plastic Push Button Operator 30.5mm

Product Description

The EATON E34L1 is a plastic push button operator designed for use in industrial and commercial control panel applications. This 30.5mm operator mounts into standard 30.5mm cutout panels and serves as the actuating component in momentary or maintained push button assemblies. Electricians and control panel builders install this part as the operator head, which couples with a matching contact block to complete the switching circuit. The plastic construction keeps the unit lightweight at 0.02 pounds and suits general-duty environments where metal operators are not required.

This operator is suited for use in motor control centers, machine control panels, and general industrial enclosures requiring a 30.5mm push button format. It fits into standard 30.5mm panel cutouts common across light manufacturing, process control, and building automation applications. Licensed electricians and panel builders typically install this component during new panel builds or when replacing worn or damaged operator heads in existing assemblies.

Key Features

• 30.5mm mounting format fits standard industrial panel cutouts
• Plastic construction for lightweight general-duty use
• Compact footprint: 1.5 inches x 1.0 inches x 0.6 inches
• Designed to pair with compatible contact blocks for complete switch assembly
• Low unit weight of 0.02 pounds simplifies panel handling

Compatibility

Designed as an OEM-style operator head for 30.5mm push button assemblies in industrial and commercial control panel applications.

Installation Notes

Installation should be performed by a qualified electrician with the panel or machine de-energized and locked out per NFPA 70E lockout/tagout procedures. The operator head inserts into the panel cutout from the front and secures with the retaining nut from the rear before the contact block is attached. Verify the cutout diameter matches the 30.5mm specification before installation. Do not overtighten the retaining nut, as plastic operator bodies can crack under excessive torque.

Technical Specifications

• Material: Plastic
• Mounting Diameter: 30.5mm
• Dimensions (L x W x H): 1.5 inches x 1.0 inches x 0.6 inches
• Weight: 0.02 pounds
• UPC: 78211370318

Standard Information

• Brand: EATON
• Manufacturer Part Number: E34L1
