Eaton E30KLA2 Multi-Function Square Standard Contact Block 30.5 mm

Product Description

The EATON E30KLA2 is a multi-function square standard contact block designed for use with E30 series pushbuttons. It features a single normally closed (1NC) contact and pressure terminal connections. The contact block has enclosed silver contacts with reliability nibs for improved switching performance.

• E30 series
• Standard Contact Block
• 1NC

Product Highlights

Eaton E30KLA2 contact block with 1NC contact configuration, pressure terminals, and a 30.5mm size, suitable for industrial control panels.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: E30KLA2
• Country of Origin: United States

Technical Specifications

• Type: 30.5 Mm, Square Multifunction
• Brand: Eaton
• Height: 2.2 Inch
• Length: 1.3 Inch
• Voltage: 250 Volt
• Terminal Type: Pressure
• Contact Configuration: 1 NC (standard)
• Block Material: Phenolic
• Mounting Type: 4-Stack
• Operator Type: Push Button
• Series: E30
• Size: 30.5 mm
• Contact Rating: 600 VAC/250 VDC
• Voltage DC: 250 Vdc
• Application: Electrical Assemblies, Panel, EOEMs, Stationary Machinery and Equipment Outside Factory, Automation and Logic Control Equipment Applications
• Manufacturer Part Number: E30KLA2
• Standards/Approvals: CSA Certified|UL Listed
• Alternate Mfr Part Number: E30KLA2
• Terminals: Pressure
• Part Number: E30KLA2
• Manufacturer: Eaton
• Category: Motor Control
• Item Subcategory: Motor Control Part And Accessory
• Section: Contact Block
• Compatible Frames: FDB,FD,HFD,FDC
• Country of Origin: United States
• Certification: CSA Certified,UL Listed
