Eaton E30AL Pushbutton Release Bar with Off Function

Product Description

The EATON E30AL is a release bar accessory designed for use with pushbutton operator assemblies in industrial control applications. The release bar provides an off-function mechanical interlock, allowing the operator to disengage or de-energize a control circuit by pressing the bar assembly. It is intended for panel-mount installations on control stations, enclosures, or operator interface panels. Licensed electricians and industrial controls technicians are the primary installers of this component. At 0.25 pounds and compact dimensions, the E30AL integrates cleanly into tight panel layouts without adding significant bulk to the assembly.

The E30AL is suited for use in commercial and industrial control panel applications where a pushbutton operator requires an off-function release mechanism. Typical installations include motor control panels, machine control stations, and operator interface enclosures. This component is commonly used in applications where a dedicated off or stop function must be accessible alongside other pushbutton operators, providing a clear and mechanically distinct de-energize action for the circuit.

Key Features

• Release bar design provides a dedicated off-function action for pushbutton operator assemblies
• Compact footprint at 2.0 x 2.0 x 2.1 inches allows installation in space-constrained panels
• Lightweight construction at 0.25 pounds minimizes added load on panel door or enclosure
• Designed for panel-mount integration with compatible E30 series pushbutton hardware
• UPC: 78211321412

Compatibility

Designed as an OEM-style accessory release bar for use with E30 series pushbutton operator assemblies in industrial panel-mount control applications.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize and lockout/tagout the control panel before beginning any work on pushbutton operators or associated hardware. Verify mechanical alignment with the mating pushbutton operator assembly before securing the release bar in place. Do not force the component into position, as improper seating can affect the reliability of the off-function action.

Technical Specifications

• Weight: 0.25 pounds
• Length: 2.0 inches
• Width: 2.0 inches
• Height: 2.1 inches
• UPC: 78211321412

Standard Information

• Brand: EATON
• Manufacturer Part Number: E30AL
