Eaton E30AC 2-button Square Push Button Station

Product Description

The EATON E30AC is a 2-button square push button station designed for industrial and commercial control applications. This compact operator interface device provides momentary push button switching for starting and stopping motors, conveyors, or other electrically controlled equipment. Built to EATON's industrial control standards, the E30AC is installed by licensed electricians and industrial maintenance technicians as part of a machine control or motor starter circuit. Its square form factor suits standard enclosure cutout patterns commonly found in industrial panels and operator stations.

The E30AC is suited for use in light industrial, commercial, and manufacturing environments where a compact, two-function push button station is required. Typical installations include motor start/stop control at the machine level, conveyor control stations, and pump control panels. The square housing integrates into standard operator station enclosures and control panel cutouts.

Key Features

• 2-button configuration supports start and stop or two-circuit switching functions
• Square form factor fits standard industrial panel and enclosure cutout layouts
• Compact and lightweight construction at 0.25 pounds
• Suitable for use as a local operator control station in machine and motor circuits
• Designed for straightforward mounting in industrial control enclosures

Compatibility

Designed as an OEM-style replacement or direct-install push button station compatible with standard industrial control enclosures accepting square operator station form factors.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the control circuit before wiring or replacing this station. Verify control voltage and contact ratings are appropriate for the connected load before restoring power. Do not exceed the rated electrical capacity of the push button contacts.

Technical Specifications

• Configuration: 2-Button Square
• Weight: 0.25 pounds
• UPC: 78211321404

Standard Information

• Brand: EATON
• Manufacturer Part Number: E30AC
