EATON E2KE3400WU66 Molded Case Mining Circuit Breaker

Product Description

The EATON E2KE3400WU66 is a three-pole molded case circuit breaker that is specifically designed for mining applications. This circuit breaker features an electronic LSI trip unit with a trip rating that ranges from 500 to 2500 Amperes. It operates at a voltage rating of 600 Volts AC and 250 Volts DC, making it suitable for heavy-duty use in various environments.

• Three-pole design for enhanced functionality
• Electronic LSI trip type for reliable overload protection
• Versatile voltage range of 600 Vac and 250 Vdc

Product Highlights

Reliable protection for mining applications, with an emphasis on safety and performance.

Product Information

Standard Information

• Brand: EATON
• MPN: E2KE3400WU66

Technical Specifications

• Amperage Rating: 400 A
• Voltage Rating: 600 Vac, 250 Vdc
• Trip Type: Electronic LSI
• Circuit Breaker Type: E2KE
• Circuit Breaker Frame Type: Complete breaker
• Terminals: Without terminals
• Undervoltage Release: 120 Vac rear with left pigtail
• Frame Type: K
• Class: Mining
• Interrupt Rating: 10 kAIC at 250 Vdc, 35 kAIC at 480 Vac, 65 kAIC at 240 Vac, 25 kAIC at 600 Vac
• Number of Poles: Three-pole
• Product Dimensions: 4.1 in x 5.5 in x 5.5 in
• Product Weight: 11.5 lb
• Certifications: UL Listed, CSA Certified
• Configuration: U66 Option Includes: [110-127VAC UVR Installed, Left Pole Mounted, Exiting Rear]
• Connection: Bolt On
• Trip Setting: 200-1500
• Standard Lug Type: Without Terminals
