Eaton E22NS38 Standard Type Push Button

Product Description

The EATON E22NS38 is a standard type push button operator designed for use in industrial control panel applications. This operator mounts into a standard 22 mm cutout and provides a reliable momentary or maintained contact actuation point for control circuits. It is suited for use in machine tool, process control, and general industrial environments where a compact, dependable operator is required. Licensed electricians and industrial control panel builders typically source this component for new panel builds and retrofit installations.

The E22NS38 fits into standard 22 mm panel cutouts common across a wide range of industrial control enclosures and operator interface stations. It is appropriate for both light-duty and general-duty control applications in residential, commercial, and industrial settings where a standard push button operator is called for.

Key Features

• Standard type operator designed for 22 mm panel cutout mounting
• Compact, lightweight construction at 0.01 pounds
• Suitable for use in general industrial control panel applications
• Compatible with standard E22 series contact blocks and accessories

Compatibility

Designed as an OEM-style operator for use in standard 22 mm industrial control panel installations. No specific compatible model numbers or system families were provided in the product data.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements. De-energize the control panel and verify zero energy state before removing or installing any operator or contact block. Ensure the panel cutout diameter matches the operator specification before mounting. Follow the manufacturer documentation for proper contact block attachment and torque guidance.

Technical Specifications

• Weight: 0.01 pounds
• UPC: 78211335968

Standard Information

• Brand: EATON
• Manufacturer Part Number: E22NS38
