Eaton E22NS37 Standard Type Push Button Operator

Product Description

The EATON E22NS37 is a standard type push button operator designed for industrial and commercial control panel applications. This operator mounts into a standard 22mm cutout and serves as the human interface component in motor control, machine automation, and process control circuits. Electricians and panel builders install this operator when building or servicing operator interface stations. At 0.020 pounds, the E22NS37 is a compact, lightweight component suited for high-density panel layouts where space and weight constraints matter.

The E22NS37 is used in industrial control panels, machine tool enclosures, and commercial automation systems wherever a standard 22mm push button operator is required. It is appropriate for both new panel builds and replacement installations in existing operator interface stations. Licensed electricians and industrial control panel builders are the primary installers of this device.

Key Features

• Standard type operator configuration for broad control panel compatibility
• 22mm industry-standard mounting footprint for easy integration
• Lightweight construction at 0.020 pounds supports high-density panel designs
• Designed for use in motor control and machine automation interface stations

Compatibility

Designed as an OEM-style replacement or new-build component for standard 22mm push button operator stations in industrial and commercial control panel assemblies.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements. De-energize and lock out the control panel before servicing or installing any operator interface components. Ensure the mounting cutout matches the 22mm standard before securing the operator. Verify all contact block and legend plate accessories are fully seated and latched before returning the panel to service.

Technical Specifications

• Weight: 0.020 pounds
• UPC: 78211335967

Standard Information

• Brand: EATON
• Manufacturer Part Number: E22NS37
