Eaton DT321UGK K Series Heavy Duty Non-Fusible Safety Switch, 240 VAC/250 VDC, 30 A

Product Description

The Eaton DT321UGK is a heavy-duty double-throw non-fused safety switch designed for reliable performance in various applications. With a rated current of thirty amps, this safety switch operates at two hundred forty volts alternating current and two hundred fifty volts direct current. It features a three-pole and three-wire design, suitable for commercial and institutional power distribution.

• Type: Double-Throw Non-Fused Safety Switch
• Material: Steel with NEMA 1 enclosure
• Applications: Ideal for power distribution in commercial settings

Product Highlights

This safety switch offers built-in interlocks to ensure safe operation, preventing simultaneous closure of both switches. It is designed to handle high short-circuit current ratings, making it applicable in critical electrical systems.

Product Information

Standard Information

• Brand: Eaton
• MPN: DT321UGK

Technical Specifications

• Voltage: 240 VAC, 250 VDC
• Amperage: 30 A
• Number of Wires: 3
• Height: 25.02 inches
• Length: 11.19 inches
• Width: 11.95 inches
• Weight: 34 lb
• Enclosure Type: NEMA 1
• Material: Painted Steel
• Number of Poles: 3
• Country of Origin: United States
• Standards: UL Listed
• Short Circuit Current Rating: 100 kA
