Eaton DSD923 DSD 2CIRC 2POSI SEL-SW R/T

Product Description

The Eaton DSD923 is a selector switch cover and device sub-assembly designed for motor control applications. This component is made from Feraloy iron alloy and features maintained contacts with a voltage rating of six hundred volts AC. It supports two circuits and two positions, making it suitable for various electrical control tasks.

• Constructed from durable Feraloy iron alloy
• Maintained contact for reliable operation
• Rated for 10 amps and six hundred volts AC

Product Highlights

This selector switch cover ensures safety and efficiency in power distribution and control systems.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Crouse Hinds

Technical Specifications

• Type: Selector switch cover and device sub-assembly
• Action: Maintained
• Vendor: 227401
• Weight: 3.2 lbs
• Material: Feraloy
• Standard: UL 1203; CSA C22.2
• Enclosure: Class I Div 1 2 Group B C D; Class II Div 1 Group E F G; Class II Div 2 Group F
• Family group: MOTOR CONTROL
• Voltage Rating: 600 VAC
• Amperage Rating: 10 A
• Application: Industrial facilities and factories
• Special Features: Factory sealed
• Dimensions: 5.2 inches x 6.8 inches x 4.6 inches
