Eaton DH326NGK Heavy Duty Fusible Safety Switch 600 Amp 240 Volt NEMA 1

Product Description

The Eaton DH326NGK is a heavy duty fusible safety switch rated at six hundred amps, designed for three-pole, four-wire configurations. This switch operates at two hundred forty volts and features a NEMA one enclosure, crafted from painted steel material. It's suitable for commercial and institutional building applications, focusing on power distribution and controls.

• Fusible safety switch with a six hundred amp capacity
• Meets compliance with NEC 230.62 (C)
• Designed for indoor use

Product Highlights

This safety switch provides a reliable means of disconnect for equipment protection and operator safety.

Product Information

Standard Information

• Application: Commercial / Institutional Buildings / Structures
• Material: Painted steel

Technical Specifications

• Amperage Rating: 600 A
• Voltage Rating: 240 V
• Number of Poles: 3 Pole
• NEMA Rating: 1
• Height: 51.82 in
• Width: 23.66 in
• Standard: UL Listed, NEC compliant
• Max Hp: 75
