Eaton DFJ-35 BUS 600V Fuse Quick Acting Current Limiting Class J (1)

Product Description

The Eaton DFJ-35 is a current limiting high-speed drive fuse designed for maximum protection in electrical applications. This fuse is rated for thirty-five amps and can operate at six hundred volts AC or four hundred fifty volts DC. It is suitable for use in systems requiring significant protection, such as variable speed drives and electric controllers.

• Fast-acting and reliable protection for AC and DC drives.
• Standard class J dimensions for compatibility with existing fuse blocks.
• Lowest let-through energy for branch circuit protection.

Product Highlights

This fuse serves as an essential component for industrial facilities, providing robust protection for sensitive electrical devices.

Product Information

Standard Information

• Manufacturer: Eaton
• UPC: 05171265333

Technical Specifications

• Amperage Rating: 35 A
• Voltage Rating: 600 VAC/450 VDC
• Class: J
• Body Size: 1.06 in Dia x 2.38 in L
• Body Type: Cylindrical
• Element: Silver
• Indicating: Non-Indicating
• Material: Melamine
• Mounting Type: Stud
• Standards/Approvals: CE Certified, CSA C22.2 File No.53787, RoHS Compliant, UL 248-8 File No.E4273 Guide JDDZ
