Eaton D93250ACZ2 24 to 280 VAC/3 to 32 VDC 50 Amp SPST-NO Solid State Relay

Product Description

The Eaton D93250ACZ2 is a solid-state relay designed for efficient control in various automation applications. This relay operates with input voltages from three to thirty-two volts DC and can handle output voltages from twenty-four to two hundred eighty volts AC. With a rated operational current of fifty amps and an SPST-NO contact configuration, this relay provides reliable switching capabilities.

• Input voltage range: Three to thirty-two volts DC
• Output voltage range: Twenty-four to two hundred eighty volts AC
• Rated operational current: Fifty amps

Product Highlights

This relay features zero-cross switching and comes with an IP20 enclosure, making it suitable for various industrial environments.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Cutler-Hammer / Eaton

Technical Specifications

• Type: D93 Series Solid-State Relay
• Width: Two point twenty-eight inches
• Height: One point seventy-four inches
• Length: Zero point sixty-six inches
• Weight: Zero point twenty-seven pounds
• Voltage: Twenty-four to two hundred eighty VAC, thirty-two VDC
• Amperage: Fifty amps
• Standard Compliance: RoHS Compliant, UL 508, CSA, CE Marked
• Enclosure: IP20
• Contact Configuration: One SPST - One NO
