Eaton D7PR3A General Purpose Relay 120VAC

EATON
Brand: EATON
SKU: D7PR3A
Availability: In Stock

Ships same day if ordered by 12 pm
$26.64
$26.64
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The EATON D7PR3A is a cost-effective control relay with high dielectric strength and current carrying capacity. This general-purpose relay features a fixed contact standard, 3PDT contact form, and a 120 VAC coil. It is suitable for automation, logic control equipment, commercial, structural, and institutional building applications.

  • Arc barrier equipped relay with high dielectric strength
  • 1/2 hp at 120 VAC, 1 hp at 250 VAC switching capacity and 1.4 W coil power
  • Panel, DIN rail and flange mounting

Product Highlights

The EATON D7PR3A relay offers reliable switching for various applications, with a focus on safety and efficiency.

Product Information

Standard Information

  • Brand: EATON
  • Manufacturer Part Number: D7PR3A
  • Country of Origin: United States
Technical Specifications
Contact Rating
15 A
Enclosure Type
IP40
Frequency Rating
50/60 Hz
Mounting Type
DIN Rail/Flange/Panel
Number of Poles
3
Power Rating
1/2 hp, 1 hp, 1.4 W
Series
D7PR
Temperature Rating
-40 to 131 deg F
Terminal Type
Plug-In
Type
Fixed Contact Standard
Contact Form
3PDT
Coil Voltage
120 VAC
Catalog Number
D7PR3A
Product Length/Depth
1.5 in
Product Height
2 in
Product Width
2 in
Compliances
RoHS Compliant CE Marked
Certifications
cRUus CSA Certified
Product Type
General-purpose relay
Coil Type
Non Latching
Termination Style
Plug In, Quick Connect - 0.187" (4.7mm)
Coil Insulation
Class B
Must Operate Voltage
102 VAC
Part Status
Active
Must Release Voltage
18 VAC
Operate Time
20 ms
Operating Temperature
-40 0 C ~ 55 0 C
Contact Material
Silver Alloy
Approval Agency
CE, CSA, UL
Switching Voltage
300VAC - Max
Relay Type
General Purpose
Load - Max Switching
4500VA
Coil Resistance
2.77 kOhms
Coil Current
43.3 mA
Application
Automation, Logic Control Equipment, Commercial, Structures and Institutional Buildings Applications
Brand
Eaton
MPN
D7PR3A
