Eaton D7PF4AT General Purpose Relay 24V 4PDT

Product Description

The EATON D7PF4AT is a general purpose plug-in relay with a full featured cover and a 24V coil. This D7 series relay offers excellent functionality for controlling smaller loads and those requiring high current-carrying capacity. It features a 4PDT contact configuration and an IP40 enclosure. The relay is suitable for various applications, including renewable energy, marine vessels, and data centers.

• Features a flag indicator to show relay status
• Equipped with a color-coded pushbutton for easy identification of AC or DC coils
• Includes a finger grip cover for easy removal from sockets

Product Highlights

The D7PF4AT relay is a cost-effective control solution with high dielectric strength and current carrying capacity. It offers a range of features for easy installation and operation.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: D7PF4AT
• Country of Origin: China

Technical Specifications

• Catalog Number: D7PF4AT
• Manufacturer: Eaton
• Brand: Eaton
• Country of Origin: China
• Made in USA: No
• Application: Generation - Renewable Energy - Alternative Energy|Marine Vessels and Equipment - Marine Vessels and Equipment - Other|Other|Datacenters - IT Space: CI and Hyper Converged|Generation - Conventional Energy - Conventional Energy
• Contact Configuration: 4PDT
• Contact Rating: 15 A
• Enclosure: IP40
• Standard: CSA file No. LR217069,cRUus,CSA file No. LR217017,UL Listed file E37317,UL Listed file E65657,CE Marked,RoHS Compliant
• UPC: 782116485031
• GTIN: 00782116485031
• Item Type: General-purpose relay
• Frequency Rating: 50/60 Hz
• Mounting Type: DIN Rail/Panel
• Number of Poles: 4
• Power Rating: 1/2 hp, 1 hp, 1.5 W
• Series: D7PF
• Temperature Rating: -40 to 131 deg F
• Terminal Type: Plug-In
• Type: Fixed Contact Full Featured
• Amperage Rating: 20 A
• Contact Form: 4PDT
• Coil Voltage: 24 VAC
• Product Name: Eaton General-purpose relay
• Product Length/Depth: 1.54 in
• Product Height: 1.1 in
• Product Width: 1.6 in
• Compliances: RoHS Compliant CE Marked
• Certifications: UL Listed file E37317 UL Listed file E65657 CSA file No. LR217017 cRUus CSA file No. LR217069
• Product Type: General-purpose relay
• Cover: Full featured
• Options: LED test button, flag indicator, lock-down door, finger-grip cover, ID tag
• Contact Material: Silver alloy
• Resistance: 84.5 Ω
• Terminals: Plug-in
• Voltage - max: 300 V switching
• Product Series: D7PF
• Family Series: Cutler Hammer, Div of Eaton Relays, D7PF Series
• Description: D7 Series General Purpose Plug-In Relay, Full featured cover, 24V coil, 84.5 Ohms resistance, Plug-in terminal, 4PDT contact configuration, 15A contact rating, Silver alloy contacts, IP40 enclosure
• Mounting: Plug In
• Termination: .250 " Flat Blade
• Enclosure Type: Plastic
• Number of Connections: 14
• Status Indicator: Yes
• Push-to-Test: Yes
• Diode: No
• Material: Silver Alloy
• Nominal Coil Voltage: 24 VAC
• Current Rating: 1-15 A
• Mechanical Latch: No
• Safety Guided: No
• Approvals: CE, CSA, UR
• Mounting Style: Plug-In/On
• Maximum Amperage: 15 A
• Model: Eaton D7PF4AT
• Number of Pins: 14-Pin
• Features: LED Test Button, Flag Indicator, Lock-Down Door, Finger Grip Cover, ID Tag
