Eaton D5RF3A Ice Cube Relay, 3PDT, 10A, 120VAC Coil

Product Description

The EATON D5RF3A is a general-purpose ice cube relay with a 3PDT contact configuration and a 10A contact rating. It features a 120VAC coil and is suitable for DIN rail or panel mounting. This relay is designed for various commercial and industrial applications.

• Flag indicator shows relay status in manual or powered condition
• LED status lamp shows coil ON or OFF status - ideal for use in low light applications
• Push to test button allows for manual operation of relay without the need for coil power

Product Highlights

Full featured with locking pushbutton, LED, test button, removable ID tag, flag indicator, and finger-grip cover.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: D5RF3A
• Country of Origin: China

Technical Specifications

• GTiN: 00786685930558
• Type: Ice Cube, Full Featured
• Brand: Eaton
• Height: 1-1/2 Inch
• Length: 3 Inch
• Voltage: 300 Volt
• Amperage: 16 Amp at 120/277 VAC/28 VDC
• Material: Polycarbonate
• Product UPC: 78668593055
• 12-Digit UPC: 786685930558
• Applications: Commercial / Institutional Buildings / Structures - Commercial / Institutional Buildings / Structures - Other
• Power Rating: 1/3 hp, 1/2 hp
• Mounting Type: DIN Rail/Panel
• Contact Rating: 10 A
• Number of Poles: 3
• Contact Material: Silver Alloy
• Operating Cycles: 5000000 Mechanical, 100000 Electrical
• Temperature Rating: -40 to 131 degrees F
• Dielectric Strength: 1500 VAC Between Coil and Contact, 1500 VAC Between Poles
• Contact Configuration: 3PDT
• Environmental Conditions: -40 to 185 F Storage
• Coil Voltage: 120 VAC
• Enclosure: IP40
• Frequency Rating: 50/60 Hz
• Manufacturer Part Number: D5RF3A
• Series: D5RF Series
• Standards/Approvals: UL Listed|cULus Recognized|CSA Certified|CE Marked
• Terminal Type: Plug-In
• Poles: 3
• Volts AC Control: 120
• Volts AC: 300
• Mounting: Socket
• Base: 11-Blade
• Nominal Coil Voltage: 120 VAC
• Current Rating: 10 A
• Approvals: CE, CSA, UL
• Contact Current Rating: 10 Amp
• Contact Voltage Rating: 300 Volt
• Model: D5RF3A
• MPN: D5RF3A
• Condition: New
• Country of Origin: China
• Category: Business & Industrial
