EATON D3RF2T RELAY PRP GENL 10A 8 DPDT 24VAC

Product Description

The EATON D3RF2T is a full-featured general-purpose relay with a rated contact capacity of ten amps. It operates with a twenty-four volt alternating current coil and features eight pins in a dual-pole, double-throw configuration. The design follows an octal base layout, making it suitable for various applications.

• Contact operation can be verified using a push-to-test button.
• LED status indicator provides visible feedback on relay status.
• Socket-mounted design allows for easy installation and removal.

Product Highlights

This relay includes features such as manual operation without coil power and a lockdown mechanism for secure functionality. Its performance is reliable in temperatures ranging from negative forty to one hundred thirty-one degrees Fahrenheit, and it offers IP40 rated protection.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: D3RF2T

Technical Specifications

• Type: Ice Cube Full Featured
• Contact Rating: 10 A
• Coil Voltage: 24 VAC
• Contact Form: DPDT
• Number of Pins: 8
• Dimensions: 2.2 in L x 1.37 in W x 1.39 in H
• Enclosure Type: IP40
• Operating Temperature Rating: -40 to 131 deg F
