Eaton D2RR2R1 Dc Operated Relay

Product Description

The EATON D2RR2R1 is a DC operated relay designed for use in industrial and commercial control circuits. This relay responds to a DC control signal to open or close one or more contact sets, enabling switching of loads in automated or manually triggered electrical systems. It is a direct-connection control component typically installed by licensed electricians or industrial control technicians in panel-mounted or DIN-rail applications where reliable electromechanical switching is required.

The D2RR2R1 is suited for use in commercial and industrial electrical control panels, motor control centers, and automation enclosures. It is appropriate for applications where a low-voltage DC coil signal must switch a separate load circuit. Installation is typical in new construction and retrofit control panel builds across commercial and light industrial settings.

Key Features

• DC operated coil for compatibility with low-voltage DC control circuits
• Electromechanical relay contact design for reliable load switching
• Compact form factor suited for panel-mount or enclosure installation
• Manufactured by EATON, a recognized name in electrical control components

Compatibility

Designed as an OEM-style replacement or direct-install relay for DC-controlled industrial and commercial electrical control panel applications.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the control panel before removing or installing the relay. Verify that the DC coil voltage of the relay matches the control circuit supply before making connections. Do not exceed the relay contact ratings for the switched load circuit.

Technical Specifications

• Operation Type: DC Operated
• UPC: 78668592985

Standard Information

• Brand: EATON
• Manufacturer Part Number: D2RR2R1
