Eaton D1RF1A1 General Purpose Ice Cube Relay 15 A

Product Description

The EATON D1RF1A1 series relay provides a compact single pole relay capable of handling 15 A. Multiple feature and voltage options allow for the perfect fit for any application. It is a full featured general purpose ice cube relay.

• The contact operation can be easily checked by push-to-test button
• Flag indicator shows relay status in manual or powered condition
• LED status lamp shows coil ON or OFF status - ideal for use in low light applications

Product Highlights

The D1RF series relay is a single pole relay capable of handling 15 A. Ideal for commercial and institutional buildings.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: D1RF1A1

Technical Specifications

• Series: D1RF
• Type: General-purpose relay
• Amperage Rating: 15 A
• Contact Form: SPDT
• Coil Voltage: 110 VDC
• Product Name: Eaton General-purpose relay
• Catalog Number: D1RF1A1
• Product Length/Depth: 1.75 in
• Product Height: 1 in
• Product Width: 2 in
• Compliances: RoHS Compliant CE Marked
• Certifications: UL Listed
• Application: Commercial, Institutional Buildings and Structures
• Brand: Eaton
• Current Type: AC
• Number in Pack: 1
• MPN: D1RF1A1
• Order code / Manufacturer SKU: D1RF1A1
• Manufacturer product status: Commercialized
• Manufacturer description: ICE CUBE RELAY - SPDT - 15A - 110Vdc COIL
