Eaton CS120BK Wiring 20-Amp 120/277-volt Commercial Grade Single Pole Compact Toggle Switch with Side Wiring

Product Description

The EATON Wiring CS120BK is a 20-Amp, 120/277-volt commercial grade single pole compact toggle switch with side wiring. Features a heavy-duty cam action mechanism for quiet switch action. Side wire terminals accept up to #10 solid or stranded wire. Ideal for use with fluorescent lighting fixtures typical in commercial applications.

• Rated for 20-Amps and 120/277-volts
• Heavy-duty cam action mechanism ensures quiet switch action
• Side wire terminals accept up to #10 solid or stranded wire

Product Highlights

This EATON toggle switch is engineered for reliable performance in commercial applications. It features a heavy-duty cam action mechanism for quiet operation and side wiring for easy installation.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: CS120BK
• Country of Origin: China

Technical Specifications

• Color: Black
• Finish: Black
• Voltage: 120/277 VAC
• Material: PVC
• Switch Type: Single Pole
• Power Source: Wired Electric
• Switch Style: Toggle
• Mounting Type: Wall
• Connector Type: Screw
• Current Rating: 16-30 A
• Operation Mode: ON-OFF
• Specification Met: CSA, UL, NOM
• Amperage: 20 A
• Power Rating: 1/2 hp
• Grade: Heavy Duty Specification Grade
• Wiring: Side wire
• Terminal: Ground screw terminal standard
• Poles: 1
• Actuator: Cam
• Temperature: -40 to 65 deg c
• Overall Length: 3.28 in
• Overall Width: 1.13 in
• Overall Depth: 0.87 in
• Application: Commercial
• Product Name: Eaton commercial grade toggle switch
• Catalog Number: CS120BK
• UPC: 032664750786
• Product Length/Depth: 1.3 in
• Product Height: 4.2 in
• Certifications: cULus Listed NOM Federal Specification Classification 6241 05
• Product Type: Commercial grade toggle switch
• Type: Toggle switch
• Amperage Rating: 20A
• Voltage rating: 120/277 V
• Number of poles: Single-pole
• Wiring method: Side wire
• Switch type: Single-pole
• Mounting method: Flush
• Load type: LED Fan MLV HAL Motor Control ELV FLR CFL INC
• Allowable wire size: #14-10 AWG
• Terminal enclosure material: Brass
• Model: CS120BK
• Operation Method: On/Off
• Brand: Eaton
• Features: Heavy Duty
• Suitable For: Wall
• Number Of Poles: 1
• Operating Cycles: 50000
• Environmental Conditions: -40 to 65 deg C
• Terminal Type: Screw
• Standard & Approvals: CSA Certified to C22.2 No. 111 File No. 10016 (6241-05), cULus Listed to UL 20 File No. E18704, RoHS Compliant, UL Verified to Federal Specification WC-896G
• Catalog ID: EAGCS120BK
