EATON CHP08B200RF CENTER LOAD BRKR MAIN 120/240VAC 200A 16 REPLACEMENT MPN

Product Description

EATON CHP08B200RF Main Load Center is designed for power distribution in residential and light commercial settings. This load center operates on 120/240 VAC and has an amperage rating of 200 A. It features 16 poles and provides a 10 kA interrupt rating.

• Includes cover and hub closure plate
• NEMA 3R rated for outdoor installation
• Plug-on mounting for easy setup

Product Highlights

This load center is ideal for managing circuit distributions and protecting branch circuits. It is suitable for overhead feed applications and comes equipped with bonded Z-straps for flexible installation options.

Product Information

Standard Information

• Type: 1-Phase Rainproof
• Manufacturer: EATON

Technical Specifications

• Voltage Rating: 120/240 VAC
• Amperage Rating: 200 A
• Number of Circuits: 8
• Number of Poles: 16
• Wiring Configuration: 3
• Dimensions: 29 inches L x 14.31 inches W x 5.19 inches H
• Enclosure Type: NEMA 3R
• Housing Material: Sheet Steel
• Interrupt Rating: 10 kA
• Number of Spaces: 8
• Breaker Type: CH/CSR
