Eaton CHF230 CH 2 Pole, 30 Amp, Plug-On Circuit Breaker, 120/240 Volt

Product Description

The EATON CHF230 is a type CHF thermal magnetic circuit breaker designed for residential and light commercial applications. This 2-pole breaker provides overload protection and trips to the OFF position, with a trip flag to indicate when tripped. It is suitable for use in CH load centers and meter breaker panels.

• Advanced electronics to reduce unwanted tripping
• Standard LED indicates one of seven trip codes to simplify circuit diagnostics
• Eliminates unwanted tripping due to loose pigtail connections

Product Highlights

This Eaton circuit breaker offers reliable circuit protection with clear trip indication and enhanced diagnostics for residential and commercial electrical systems.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: CH-CHF230

Technical Specifications

• Amperage Rating: 30 A
• Voltage Rating: 120/240V
• Actuator: Toggle Handle
• Application: Circuit Protection, Residential Type CH Load Centers and Meter Breaker Panels, Light Commercial Distribution Panels, Pool Panels, Residential Transfer Switch Panels and Various OEM Applications
• Catalog Description (MFR): Eaton CH Thermal magnetic circuit breaker, Type CHF 3/4-Inch standard circuit breaker, 30 A, 10 kAIC, Two-pole, 120/240V, CHF, Trip flag, common breaker trip, (1) #14-8 AWG, (2) #14-10 AWG Cu/Al, CHF, Type CH Loadcenters
• Certifications: UL 489
• Compliances: HACR Rated
• Interrupt Rating: 10 kA
• Mounting Type: Plug-On
• Number Of Poles: 2 Pole
• Phase: 1
• Product Name: Eaton CH thermal magnetic circuit breaker
• Product Type: Thermal magnetic circuit breakers
• Standard: UL 489,HACR Rated
• Trip Type: Trip flag
• Type: Type CHF Standard
• Wire Size: (1) 14 to 8 AWG, (2) 14 to 10 AWG Copper/Aluminum
• Used With: Type CH Loadcenters
• Main Circuit Breaker: CH
• Number of Throws: 2
• Suitable For: Exterior, Interior
• Tripping Characteristics: Type CH
• Current Type: AC
• Control Style: Switch
• Number in Pack: 1
• Features: Thermal Overload Protection, Trip Indicator
• Room: Any Room
• Protection Properties: Overload Protection, Short Circuit Protection
• Mounting Style: Plug-In/On, Unit
• Maximum Amperage: 30 A
• Number of Positions: 2
• Current Rating: 16-30 A
• Material: ABS/Plastic, Aluminized Steel, Aluminum, Plastic
• Orientation: Horizontal/Vertical
• Electrical Connection: Screw Terminal
• Brand: Eaton
• Operation Method: On/Off
• Break Time: Time Delay (Short)
• Contact Configuration: Double Pole Single Throw (DPST)
• Model: Eaton CHF230
