Eaton CHDB377F CH Power Distribution Block Enclosed 570A (12) 4-14AWG

Product Description

The EATON CHDB377F power distribution block is enclosed and part of the CHDB series. Rated at 600 VAC and 570 A, this 1-pole block accommodates (12) 14 to 4 AWG load wires and 4 AWG to 300 kcmil line wires. It features a 50 kA short circuit rating and measures 4-1/2 in L x 1-3/4 in W x 3 in H.

• IP20 finger safe enclosure
• DIN rail or panel mounting
• Tin plated aluminum connections suitable for copper conductors

Product Highlights

The EATON CHDB377F power distribution block provides a safe and flexible wiring solution for high short circuit current applications in industrial control panels.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: CHDB377F
• Country of Origin: Mexico

Technical Specifications

• Amperage Rating: 570 A
• Application: Wiring Management and Device Applications
• Manufacturer Part Number: CHDB377F
• Number of Poles: 1
• Series: CHDB
• Short Circuit Current Rating: 50 kA
• Standards/Approvals: UL 489|HACR Rated|Federal Speciation W-P-131a|CSA Certified
• Type: Enclosed
• Voltage Rating: 600 VAC
• Block Type: Power Distribution (Enclosed Block)
• Poles Per Block: 1
• Openings Per Pole, Primary: 1
• Conductor Size - Primary: 4 AWG to 300 MCM
• Openings Per Pole, Secondary: 12
• Conductor Size - Secondary: (12) 4-14 AWG
• Conductor Material: Copper
• Material - Connector: Tin Plated Aluminum
• Wire Size: 4 AWG to 300 kcmil Line, (12) 14 to 4 AWG Load
