Eaton CHDB330F Power Distribution Block 380A

Product Description

The EATON CHDB330F power distribution block is enclosed and part of the CHDB series. Rated at 600 VAC and 380 A, this 1-pole block accepts 6 AWG to 500 kcmil wire and 14 to 2 AWG wire. It withstands a 50 kA short circuit and measures 20 in L x 20 in W x 6-3/4 in H.

• IP20 finger safe enclosure
• DIN-rail or panel mounting
• Gang mountable for multi-pole applications
• Tin plated aluminum connections suitable for copper conductors

Product Highlights

The Eaton CHDB330F power distribution block offers a high short circuit current rating and significant wiring flexibility for industrial control panels.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: CHDB330F
• Country of Origin: Mexico

Technical Specifications

• Amperage Rating: 380 A
• Application: Wiring Management and Device Applications
• Manufacturer Part Number: CHDB330F
• Number of Poles: 1
• Series: CHDB
• Short Circuit Current Rating: 50 kA
• Standards/Approvals: UL Listed|CSA Certified|Federal Specification W-C-375B|HACR Rated
• Type: Enclosed
• Voltage Rating: 600 VAC
• Block Type: Power Distribution (Enclosed Block)
• Poles Per Block: 1
• Openings Per Pole, Primary: 1
• Conductor Size - Primary: 6 AWG to 500 MCM
• Openings Per Pole, Secondary: 6
• Conductor Size - Secondary: (6) 2-14
• Conductor Material: Copper
• Material - Connector: Tin Plated Aluminum
• Rating - Voltage: 600V
• Rating - Amps: 380
• Wire Size: 6 AWG to 500 kcmil, 14 to 2 AWG
• Overview: PWR DST BLK-380A,1P,300KCMIL-4AWG LINE,(6)2-14 LOAD,FINGSAF
• Manufacturer Name: Eaton
