Eaton CH220GFT Type CH Ground Fault Self-Test Circuit Breaker, 120/240 VAC, 20 Amp, 10 kAIC, 2-Pole

Product Description

The Eaton CH220GFT is a type CH ground fault self-test circuit breaker with a voltage rating of one hundred twenty to two hundred forty volts alternating current (VAC) and an amperage rating of twenty Amps. This unit features a ten thousand Amp interrupt rating and uses a common trip mechanism. It is designed to provide safety in circuits near water.

• Self-test capability for enhanced reliability
• Suitable for residential and commercial applications
• Trip mechanism prevents nuisance tripping

Product Highlights

This circuit breaker aims to prevent electrical shock in wet areas like kitchens and bathrooms. It immediately interrupts the circuit upon detecting ground faults.

Product Information

Standard Information

• Brand: Eaton
• MPN: CH220GFT

Technical Specifications

• Voltage Rating: 120/240 VAC
• Amperage Rating: 20 A
• Interrupt Rating: 10 kAIC
• Number of Poles: 2
• Connection Type: Plug-On
• Trip Type: Common
• Wire Size: 14 to 4 AWG
• Dimensions: 4-1/2 in L x 2-3/4 in W x 2 in H
• Temperature Rating: 60 to 75 deg C
• Enclosure Type: NEMA 1/3R
