Product Description
The Eaton CH220 is a 20 Amp, 2-pole circuit breaker designed for circuit protection. This Type CH 3/4-inch standard circuit breaker operates at 120/240V with a 10 kAIC interrupt rating. It is suitable for use with type CH load centers and provides thermal-magnetic protection for 240V branch circuits.
- Type CH 3/4-inch Standard Circuit Breaker
- Two-Pole, 120/240V
- Interrupt Rating: 10 kAIC
Product Highlights
Provides reliable circuit protection with long-time and instantaneous trip functions. It mounts into 3/4-inch spaces within Eaton and Cutler-Hammer Type CH load centers.
Product Information
Standard Information
-
Brand: EATON
-
Manufacturer Part Number: CH220
-
Country of Origin: Mexico
Technical Specifications
-
Type: Type CH 3/4-inch Standard Circuit Breaker
-
Brand: Eaton
-
Width: 1.5 in
-
Height: 3-1/2 Inch
-
Length: 3 Inch
-
Voltage: 120/240 Volt
-
Amperage: 20 Amp
-
Trip Type: Common
-
Applications: Circuit Protection
-
Number of Poles: 2 Pole
-
Interrupt Rating: 10 kAIC
-
MPN: CH220
-
UPC: 782113101767
-
Manufacturer: Cutler-Hammer / Eaton
-
NorthEast Part #: 20080
-
Wire Size: (1) #14-8 AWG, (2) #14-10 AWG Cu/Al
-
Circuit Breaker Type: CH
-
Used With: Type CH Loadcenters
-
Compliance: HACR Rated
-
Certifications: UL 489
-
Poles: 2
-
Voltage Rating: 240 VAC
-
Amperage Rating: 20A
-
Maximum Amperage: 20 A
-
Trip Curve: Standard Trip
-
Interrupting Rating: 10000 AIC
-
Series: CH
-
AIC Rating: 10kA @ 120/240VAC
-
Mounting Style: Plug-In/On, Unit
-
Terminal Type: Box Lugs
-
For Use With: Type CH Load Centers
-
Trip Technology: Thermal Magnetic
-
Trip Function Code: LI
-
Trip Function: Long-Time, Instantaneous
-
Trip Adjustability: Fixed Thermal, Fixed Magnetic
-
Wire Gauge: (1) 14-8 AWG (Cu/Al), (2) 14-10 AWG (Cu/Al)
-
Max Wire: 8 AWG
-
Min Wire: 14 AWG
-
Available Options: Padlock Attachment
-
Standards: HACR, UL 489
-
Approval: CSA, UL
-
Temp Rating: 60C to 75C
-
Construction Features: Common Trip, HACR Rated
-
Part Number: CH220
-
Family: CH Series
-
Amp: 20
-
Volt: 240
-
Phase: 1
-
Category: Molded Case Circuit Breakers
-
AIC Ratings: 10kA@240V
-
Dimensions (HxWxD): 3 x 3.5 x 1.5
-
Operating Temperature: 75 °C (167 °F)
-
Plug Type: A
-
Resistance Properties: Weather Resistant
-
Room: Any Room
-
Number of Throws: 1
-
Number of Positions: 2
-
Color: Multicolor
-
Number of Phases: 1
-
Current Rating: 16-30 A
-
Material: ABS/Plastic, Aluminum, Plastic, Metal
-
Suitable For: Wall, Interior, Exterior
-
Electrical Connection: Screw Terminal
-
Tripping Characteristics: Type A
-
Operation Method: On/Off
-
Current Type: AC
-
Control Style: Switch
-
Break Time: Time Delay (Short)
-
Number of Ports: 1
-
Number in Pack: 1
-
Number of Outlets: 2
-
Features: Thermal Overload Protection, Plug-On Neutral, Trip Indicator
-
Protection Properties: Overload Protection
-
Timer Control: None
-
Orientation: Vertical
