Eaton CE15BN2BB XT IEC contactor 10A 45 mm

Product Description

The EATON CE15BN2BB XT IEC contactor is designed for efficiency and reliability. This two-pole contactor supports 220-240 Vac and features a steel mounting plate. Ideal for various applications, it has a 10A amperage rating and a compact 45 mm frame size. It is a non-reversing contactor with no overload relay.

• 10A amperage rating
• 220-240 Vac coil voltage
• Steel mounting plate

Product Highlights

The EATON CE15BN2BB is a reliable and efficient IEC contactor with a compact design and durable construction.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: CE15BN2BB
• Country of Origin: US

Technical Specifications

• Product Name: Eaton XT IEC contactor
• Catalog Number: CE15BN2BB
• UPC: 782113778181
• Product Length/Depth: 3.25 in
• Product Height: 2.96 in
• Product Width: 1.8 in
• Compliances: ISO 9000 DIN VDE 0600
• Certifications: IEC Rated UL Listed CSA Certified
• Catalog Notes: No enclosure
• Product Type: Contactors
• Amperage Rating: 10A
• HP rating - max: 1 hp
• Number of poles: 2
• Type: Contactor
• Frequency rating: 50-60 Hz
• Frame size: 45 mm
• Coil voltage: 220-240 Vac, 50-60 Hz
• Continuous ampere rating: 10 A
• Relay: No overload relay
• Series: Freedom
• Operation: Non-reversing
• Mounting method: Steel mounting plate
• UNSPSC: 39121529
• Terminal Type: Box Lug
• Enclosure Type: Open
• Size: 45
• Dimensions: 3.25 in L x 1.8 in W x 2.96 in H
• Maximum Load Current: 10
• Item: IEC Magnetic Contactor
• Amps Rating: 10A
• Continuous Amps Rating: 10A
• Height: 2.96 in
• Length: 3.25 in
• Max. Hp Rating: 1 hp
• Mfr. Series: Freedom Series
• Notes: No Enclosure
• Width: 1.8 in
• Construction Standard: I.E.C. 600V AC
• UL Cont. Amps: 10A
• Poles: 2P
• Hp 1-Phase 115V: 0.5 Hp
• Hp 1-Phase 230V: 1 Hp
• UNSPSC Code: 39120000
• Brand: Eaton - Cutler Hammer
• Manufacturer Part Number: CE15BN2BB
• Unit of Measure: EA
• Category: Contactor
• Weight: 1.00 lbs
