Eaton CE15AN3AB XT IEC contactor 110-120 Vac

Product Description

The EATON CE15AN3AB is an XT IEC contactor, designed for use in applications where running overcurrent protection is either not required or is provided separately and power control equipment. It features a steel mounting plate and is a three-pole, non-reversing contactor. No overload relay.

• Horizontal or vertical mounting on upright pane allows for application freedom
• Screw type power terminals have captive, backed out self lifting pressure plates with screws result in reduced wiring time
• Accessible terminals allow for ease of use and are convenient for simple wiring

Product Highlights

The EATON CE15AN3AB contactor is suitable for motor and power control equipment applications.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: CE15AN3AB
• Country of Origin: Dominican Republic

Technical Specifications

• Product Name: Eaton XT IEC contactor
• Catalog Number: CE15AN3AB
• UPC: 782113777870
• Product Length/Depth: 3.25 in
• Product Height: 2.96 in
• Product Width: 1.8 in
• Compliances: ISO 9000 DIN VDE 0600
• Certifications: CSA Certified UL Listed IEC Rated
• Catalog Notes: No enclosure
• Product Type: Contactors
• Amperage Rating: 7A
• HP rating - max: 0.25 hp
• Number of poles: 3
• Type: Contactor
• Frequency rating: 50-60 Hz
• Frame size: 45 mm
• Coil Voltage: 110 VAC at 50 Hz, 120 VAC at 60 Hz
• Continuous ampere rating: 7 A
• Relay: No overload relay
• Series: Freedom
• Operation: Non-reversing
• Mounting method: Steel mounting plate
• UNSPSC: 39121529
• Approval: UL, CSA
• Application: For use to switch motor loads in applications where running overcurrent protection is either not required or is provided separately and power control equipment
• Mounting Type: Surface
• Terminal Type: Screw
• Enclosure Type: Open
• Mounting: DIN Rail
• Enclosure: Open
• Construction Standard: IEC
• Contact Configuration: 1NO
• Operating Temperature: -5 to 65
• Size: 45
• UL Cont. Amps: 7A
• Poles: 3P
• Hp 1-Phase 115V: 0.25 hp
• Hp 1-Phase 230V: 0.5 Hp
• Hp 3-Phase 200V: 1.5 Hp
• Hp 3-Phase 230V: 1.5 Hp
• Hp 3-Phase 460V: 3 Hp
• Hp 3-Phase 575V: 5 Hp
