Eaton CCVH2200X type CCV tenant main circuit breaker 200A 2-pole 25kAIC

Product Description

The EATON CCVH2200X is a Type CCV Tenant Main Circuit Breaker designed for various electrical applications. This two-pole, 200 Amp breaker operates at 120/240 Volts and features a 25 kAIC interrupt rating. It is compatible with #2/0 AWG to 300 kcmil copper or aluminum wire and is suitable for Type ECC unit enclosures. This breaker serves as a main or emergency disconnect and is ideal for tenant main applications in group metering stacks.

• 200 Amp rating with 25 kAIC interrupting capacity.
• Two-pole configuration for 120/240 Volt systems.
• Compatible with #2/0 AWG-300 kcmil Cu/Al wire and Type ECC unit enclosures.

Product Highlights

Ideal for tenant main applications, group metering stacks, and main disconnects in residential or commercial settings.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: CCVH2200X
• Country of Origin: Dominican Republic

Technical Specifications

• Type: Tenant Main Circuit Breaker
• Brand: Eaton
• Voltage: 120/240 Volt
• Amperage: 200 Amp
• Wire Size: 300 kcmil
• Terminal Type: Load
• Conductor Size: 2/0 AWG
• Number of Poles: 2 Pole
• Interrupt Rating: 25 kAIC
• Standard: UL 489
• Item Type: Tenant main breaker
• Application: Other|Generation - Renewable Energy - Alternative Energy|Generation - Conventional Energy - Conventional Energy|Datacenters - IT Space: CI and Hyper Converged|Marine Vessels and Equipment - Marine Vessels and Equipment - Other
• Phase: 1 ph
• Trip Type: Thermal/Magnetic
• Mounting Type: Bolted-On
• Temperature Rating: 60 to 75 deg C
• Series: CCV
• Enclosure Type: ECC unit
• Terminals: Load side
• Includes: Frame and Terminal
• Standards/Approvals: UL 489|CSA C22.2 No. 5|AS 2184|BS 4752|IEC 60 947-2|SABS 156|SEV 157-1|VDE 0660|Federal Specification W-C-375b|HACR Rated
• Circuit Breaker Frame Type: CCV
