Eaton CCV2150X CCV, 2P, 150A, 10kAIC

Product Description

The Eaton CCV2150X is a two-pole circuit breaker designed for tenant main circuit applications. This unit has a voltage rating of 120/240 volts and an amperage rating of 150 amperes. Its interrupt capacity is 10 kAIC, providing reliable protection in critical scenarios.

• Voltage rating of 120/240 V
• 150 A amperage rating with a 10 kAIC interrupt capacity
• Compatible with #2/0 AWG to 300 kcmil wire sizes

Product Highlights

The Eaton CCV2150X serves as a key component in power distribution, specifically within tenant structures and group metering applications. The design supports both copper and aluminum wire connections.

Product Information

Standard Information

• Manufacturer: Eaton
• Catalog Number: CCV2150X

Technical Specifications

• Type: Tenant main circuit breaker
• Number of Poles: 2
• Voltage Rating: 120/240 V
• Amperage Rating: 150 A
• Interrupt Rating: 10 kAIC
• Wire Size: #2/0 AWG to 300 kcmil
• Enclosure Type: NEMA 1/3R
• Dimension: 8 in x 4.5 in x 5.5 in
• Weight: 2.83 lb
