Eaton CCV2150 CCV Breaker 150A/2 Pole

Product Description

The Eaton CCV2150 is a type CCV tenant main circuit breaker designed for reliable performance. It supports a voltage of 120/240 volts and an amperage rating of 150 amps. This double-pole breaker has an interrupt rating of 10 kAIC, making it suitable for various electrical applications, including tenant main breakers in commercial buildings.

• Voltage rating: 120/240V
• Amperage: 150A
• Application: Tenant main circuit breaker

Product Highlights

This breaker is ideal for installations in group metering stacks and works well with both copper and aluminum conductors. The wire size range is from 2 AWG to 300 kcmil. It is designed to operate in environments with a temperature range of sixty to seventy-five degrees Celsius.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Cutler-Hammer / Eaton

Technical Specifications

• Catalog Number: CCV2150
• Voltage Rating: 120/240V
• Amperage Rating: 150A
• Number of Poles: 2
• Interrupt Rating: 10 kAIC
• Dimensions: 7.7 in length x 4.5 in width x 5.4 in height
• Country of Origin: Dominican Republic
• Standards: UL 489
