Eaton CCV2125 CCV Breaker 125A/2 Pole

Product Description

The Eaton CCV2125 is a two-pole tenant main circuit breaker with a capacity of 125 Amperes and an interrupt rating of 10 kAIC. It is designed for use in low voltage power distribution applications with voltages of 120/240 Volts. The device accommodates wire sizes from #2/0 AWG to 300 kcmil, making it versatile for various installations.

• Type CCV Tenant Main Circuit Breaker
• Interrupt Rating: 10 kAIC
• Voltage: 120/240 VAC

Product Highlights

The Eaton CCV2125 circuit breaker is ideal for service entrance equipment and tenant systems, particularly in multi-tenant buildings. It is compatible with a range of accessories, enhancing its functionality in diverse electrical settings.

Product Information

Standard Information

• Manufacturer: Eaton
• UPC: 786685368399

Technical Specifications

• Amperage Rating: 125 A
• Number of Poles: 2
• Voltage Rating: 120/240 VAC
• Wire Size: 2/0 AWG to 300 kcmil
• Dimensions: 7.7 in length x 5.4 in height x 4.5 in width
• Interrupt Rating: 10 kAIC
• Temperature Rating: 60 to 75 degrees Celsius
• Made in: Dominican Republic
• Certification Standard: UL 489
