Eaton CCV2100 Type CCV Tenant Main Circuit Breaker, 120/240 VAC, 100 A, 10 kA Interrupt, 2 Poles

Product Description

The Eaton CCV2100 is a tenant main circuit breaker designed for use in various applications, especially for main service entrance equipment. This 120/240 VAC thermal magnetic breaker handles a current of up to one hundred amps and has a ten kA interrupt capacity, making it suitable for protecting electrical systems in residential and commercial applications.

• Amperage: 100 A
• Voltage: 120/240 VAC
• Number of Poles: 2

Product Highlights

This circuit breaker is ideal for tenant metering and can accommodate wire sizes from two AWG to three hundred kcmil copper or aluminum. The CCV2100 supports applications including datacenters, renewable energy systems, and more.

Product Information

Standard Information

• Manufacturer: Eaton
• Catalog Number: CCV2100

Technical Specifications

• GTIN: 00786685368337
• UPC: 786685368337
• Application: Tenant main circuit breaker
• Interrupt Rating: 10 kAIC
• Dimensions: 7.7 in L x 4.5 in W x 5.4 in H
• Temperature Rating: 60 to 75 °C
• Standard: UL 489
