Eaton CCP2-2-100CF Bussmann Compact Circuit Protector 600 VAC 125 VDC 100 A 2 Poles

Product Description

Eaton CCP2-2-100CF is a compact fused circuit protector designed for efficient electrical safety. This disconnect switch operates at 600 volts alternating current and 125 volts direct current. It has a current rating of 100 amps and features two poles, making it suitable for various electrical applications.

• Designed for 600 VAC and 125 VDC applications.
• Compact design with 35 mm DIN rail mount for easy installation.
• Rated for a maximum operating temperature range from -4 to 167 degrees Fahrenheit.

Product Highlights

This circuit protector provides reliable overcurrent protection in tight spaces.

Product Information

Standard Information

• Manufacturer: Eaton
• Manufacturer Part Number: CCP2-2-100CF

Technical Specifications

• Amperage Rating: 100 A
• Fuse Type: Class CF
• Mounting Type: 35 mm DIN Rail
• Number of Poles: 2
• Voltage Rating: 600 VAC, 125 VDC
• Width: 0.3 in
• Height: 3.7 in
• Operating Temperature: -4 to 167 deg F
• Standards/Approvals: UL 98 File No. E302370, cULus to Canadian Standard 22.2 No. 4-04 File No. E302370
