Eaton C320KGT16 Freedom NEMA Auxiliary Contact 1NCI Contacts

Product Description

The Eaton C320KGT16 Freedom NEMA auxiliary contact features a compact, space-saving design. This auxiliary contact is used on starters and contactors and has a 1NCI contact configuration with top mounting. It utilizes state-of-the-art technology and high-strength, impact and temperature-resistant insulating materials.

• 1NCI contact configuration
• Top mounting type
• Used on starters and contactors

Product Highlights

The Eaton C320KGT16 auxiliary contact is designed for use with contactors and starters, offering a reliable and compact solution for various applications.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: C320KGT16
• Country of Origin: Dominican Republic

Technical Specifications

• Catalog Number: C320KGT16
• Manufacturer: Eaton
• Brand: Eaton
• Country of Origin: Dominican Republic
• Made in USA: No
• Application: Elec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMs
• Contact Configuration: 1 NCI
• Mounting: Top
• Standard: cUL Listed
• UPC: 782113413716
• GTIN: 00782113413716
• Item Type: Accessory
• Size: SZ 0 to 2
• Suitable For Use With: Contactor and Starter
• Type: Heavy Duty
• Voltage Rating: 600 VAC
• Amperage Rating: 10 A
• Number of Contacts: 1
• Material: Silver Cadmium Alloy
• Product Length/Depth: 2 in
• Product Height: 2.1 in
• Product Width: 2 in
• Used with: Used on Starters and Contactors
• Accessories: Freedom NEMA
• Mounting method: Top
• Series: Freedom
• For Use With: Size 00 to 2 AN16 Contactors and Starters
• Nema Size: 00 to 2
• Family Series: Eaton Contactors
• Manufacturer Part Number: C320KGT16
• Net Weight: 0.1 lbs
• Gross Weight: 0.15 lbs
• Approval: cUL
