Eaton C320KG15 Auxiliary Contact 2NC For 15-75

EATON
Brand: EATON
SKU: C320KG15
Availability: In Stock

Ships same day if ordered by 12 pm
$144.42
$144.42
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The EATON C320KG15 is a side-mounted auxiliary contact with pressure plate and quick connect terminals, featuring a 2NC configuration. Designed for motor control applications, it is suitable for use with 15 to 75 A definite purpose contactors. This heavy-duty pilot-rated contact can handle 10A at 600Vac.

  • Side Mounted Auxiliary Contact
  • Pressure plate and Quick connect terminals
  • Suitable for 15-75A definite purpose contactors

Product Highlights

The EATON C320KG15 auxiliary contact provides reliable switching and control in motor starter circuits.

Product Information

Standard Information

  • Brand: EATON
  • Manufacturer Part Number: C320KG15
  • Country of Origin: Dominican Republic
Technical Specifications
Type
Motor control accessory
Brand
Eaton
Terminal Type
Pressure Plate And Quick Connect
Contact Configuration
2NC
Applications
Commercial / Institutional Buildings / Structures - Power Distribution and Controls
Catalog Number
C320KG15
Product Length/Depth
2.5 in
Product Height
4 in
Product Width
1.1 in
Catalog Notes
Heavy-Duty Pilot Rated for 10A at 600 Vac, For 15-75A Contactors
Terminals
Pressure plate and quick connect
UNSPSC
39121529
Material
Silver Cadmium Alloy
Application
Motor and Power Control Equipment Applications
Mounting Type
Side
Voltage Rating
600
Size
SZ 1
Dimensions
2.5 in L x 1.1 in W x 4 in H
Amperage Rating
10
Number of Contacts
2
Suitable For Use With
15 to 75 A Definite Purpose Contactor
Part Number
C320KG15
Manufacturer
Eaton Cutler-Hammer
Family
Freedom Series
Phase
3
Category
Motor Controls
Current Type
AC
Voltage
600 V
Current Rating
10 A
MPN
C320KG15
Suitable For
Definite Purpose Contactor
Country of Origin
China
Net Weight
0.1 lbs
Gross Weight
0.15 lbs
Main function
Auxiliary contact
Functions
Auxiliary Contact - for 15-75A cont.
Connection type
Pressure Plate and Quick Connect connection
Normally Closed (NC) auxiliary contacts
2 NC contacts
Technical compatibility with
C25
15-75A Contactors
15-75A Contactors
Manufacturer product status
Commercialized
Mounting location
Side
Configuration
2NC
